LM2500™
LM2500™
The LM2500™ is an industrial gas turbine made by GE and is based on the CF6-6 commercial aircraft engine. MTU has been providing maintenance services for it since 1981. Unlike the LM6000™ model, the LM2500™ features a single-rotor gas generator, which can be aerodynamically coupled to a power turbine. It comprises a 16-stage compressor, an annular combustor, a two-stage high-pressure turbine, and in some cases a high-performance power turbine. The LM2500™ is the most widely used gas turbine in the 25-37 megawatt power category.
The LM2500+™ and LM2500+G4™ gas turbines are uprated versions of the LM2500™ and offer 30.20 MW and 36.98 MW of power, respectively.
MTU’s involvement in the LM2500TM
MTU manufactures the disks for the front two high-pressure turbine stages and provides maintenance services for the LM2500TM at MTU Maintenance Berlin-Brandenburg.
Facts
- Generator at “hot” end
- Single-shaft gas generator with free power turbine
MTU competencies
- Manufacture of stage 1 and 2 high-pressure turbine disks
- Maintenance at MTU Maintenance Berlin-Brandenburg
Start year MRO: 1981
Shop visits (2023): > 1,000
Workscope: Engine MRO
Applications
- Power generation
- Mechanical drive systems / oil and gas extraction
- Marine propulsion
- Combined Heat and Power ("Cogen")
Technical Data
| LM2500 | LM2500+ | LM2500+G4 | |
|---|---|---|---|
| Power | 25.06 MW | 30.20 MW | 36.98 MW |
| Heat rate LHV | 9,465 Btu/kWh | 8,850 Btu/kWh | 9,184 Btu/kWh |
| Exhaust gas mass flow | 149 lb/s | 191 lb/s | 213 lb/s |
| Exhaust gas temperature | 990 F | 960 F | 945 F |
| Power turbine speed | 3,600 rpm | 3,600 rpm | 3,600 rpm |
